WTA5G Multi-Band Antenna
Multi-band 5G antenna covering 617-3800 MHz with IP65 protection. Ideal for IoT, M2M, smart metering and mobile applications on conductive surfaces.
Full Description
The WTA5G is a versatile multi-band antenna designed for professional applications requiring coverage across multiple frequency bands including LTE, 4G, 5G, and IoT networks.
Key Applications:
- IoT and M2M communications
- Smart metering systems
- Vehicle and fleet management
- Mobile data applications
- Multi-band cellular connectivity
Technical Highlights:
- Covers five frequency bands from 617 MHz to 3800 MHz
- Optimised gain across all bands for reliable connectivity
- IP65 rating when mounted for outdoor durability
- Compact and lightweight design at just 113g
- Wide operating temperature range: -40°C to +85°C
- Bolt-on mounting with adhesive for secure installation
This antenna is particularly well-suited for mounting on conductive surfaces such as car roofs, metering cabinets, and metal brackets, making it ideal for mobile and fixed installations.
Technical Information
Electrical specifications
Type
Multi-band Omni-directional Antenna
Beamwidth
Beamwidth
50 ohm
Frequency
617-960 MHz, 1427-1518 MHz, 1710-2170 MHz, 2300-2690 MHz, 3300-3800 MHz
Frequency Type
No items found.
Bandwidth
See frequency ranges
Impedance
50 Ohm
VSWR
<3.0:1 (617-960 MHz), <2.0:1 (1427-2690 MHz, 3300-3800 MHz) - Measured with 1.5m RG58 cable on Ø50cm ground plane
Polarisation
Gain
-1 dBd / 1.15 dBi (617-790 MHz), 0 dBd / 2.15 dBi (790-960 MHz), 3 dBd / 5.15 dBi (1427-2690 MHz), 5 dBd / 7.15 dBi (3300-3800 MHz) - Measured on Ø50cm ground plane
Electrical Beam-Tilt
Radiation Pattern
Half Power Beamwidth
Max. Input Power
40 W
Spacing
Insertion Loss
Isolation (Suppression)
Frequency Stabilty
Antistatic Protection
Attenuation
Insertion Loss (Tx)
Tx-Tx Spacing
Tx-Rx Spacing
Isolation Tx-Tx
Isolation Rx-Tx
Isolation Tx-Rx
Isolation Rx-Rx
Lna Noise Figure
Power Supply
Mechanical specifications
Color
Black and silver
Length
Weight
113 g
Mounting
No items found.
Mounting Place
Vertical or horizontal conductive surfaces (e.g. car roofs, metering cabinets, brackets)
Survival Wind Speed
Operating Temperature
-40°C to +85°C
Connector/ Cable / Pigtail
RG58/U cable, 1.5m. Multiple connector options available: Type N-female, SMA-male, TNC-male - specify when ordering
Ingress Protection
IP65 (when mounted)
Materials
ABS, rubber, brass, PVC, PE and PCB
Ordering information
No items found.
WTA5G (Base Product Code)
Available in multiple connector variants - see ordering information
